Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 375
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #7
Ramp Time
52 6034 24628 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #7
PID SET
167 60A7 24743 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #8 Soak
Setpoint Value
53 6035 24629 FP R/W Within Setpoint Limits
Segment #8 Soak
Time
54 6036 24630 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##8
76 604C 24652 FP R/W 0 to 99.9 (0 = no soak)
Segment #8
PID SET
168 60A8 24744 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #9
Ramp Time
55 6037 24631 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #9
PID SET
169 60A9 24745 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #10
Soak Setpoint
Value
56 6038 24632 FP R/W Within Setpoint Limits
Segment #10
Soak Time
57 6039 24633 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak #10
64 6040 24640 FP R/W 0 to 99.9 (0 = no soak)
Segment #10
PID SET
170 60AA 24746 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #11
Ramp Time
58 603A 24634 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
