Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
376 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #11
PID SET
171 60AB 24747 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #12
Soak Setpoint
Value
59 603B 24635 FP R/W Within Setpoint Limits
Segment #12
Soak Time
60 603C 24636 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak #12
78 604E 24654 FP R/W 0 to 99.9 (0 = no soak)
Segment #12
PID SET
172 60AC 24748 FP R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #13
Ramp Time
61 603D 24637 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #13
PID SET
173 60AD 24749 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #14
Soak Setpoint
Value
62 603E 24638 FP R/W Within Setpoint Limits
Segment #14
Soak Time
63 603F 24639 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak #14
79 604F 24655 FP R/W 0 to 99.9 (0 = no soak)
Segment #14
PID SET
174 60AE 24750 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #15
Ramp Time
64 6040 24640 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #15
PID SET
175 60AF 24751 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
