Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 385
10.7.7 Accutune
Table 10-16 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Adaptive Tune.
Table 10-16 Set-up Group – Adaptive Tune
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Fuzzy Overshoot
Suppression
193 00C1 193 INT R/W 0 = Disabled
1 = Enabled
Fuzzy Overshoot
Suppression Loop2
193 01C1 449 INT R/W 0 = Disabled
1 = Enable 1
2 = Enable 2
3 = Enable 12
Accutune Enable
Loop 1
152 0098 152 INT R/W 0 = Accutune Disabled
1 = Limit Tune
2 = SP Tune
3 = Tune + SP
4 = SP Tune + PV
Accutune Enable
Loop2
152 0198 408 Int R/W 0 = Accutune Disabled
1 = Limit Tune
2 = SP Tune
3 = Tune + SP
4 = SP Tune + PV
Accutune Duplex
selection
225 00E1 225 INT R/W 0 = Manual
1 = Auto
2 = Disable (blend)
Accutune Error (Read
only) Loop1
151 0097 151 INT R/W 0 = None
1 = Output Limits
2 = PV Change
Insufficient
3 = Process
Identification Failed
4 = Accutune Aborted
5 = Running
6 = Setpoint Error
Accutune Error (Read
only) Loop2
151 0197 407 INT R/W 0 = None
1 = Output > or < Output
Limits or Man Step=0
2 = PV Change
Insufficient
3 = Process
Identification Failed
4 = Accutune Aborted
5 = Running
6 = Setpoint Error
Tune Criteria 139 008B 139 INT R/W 0 = Normal
1 = Fast
