Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 377
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #16
Soak Setpoint
Value
65 6041 24641 FP R/W Within Setpoint Limits
Segment #16
Soak Time
66 6042 24642 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak #16
80 6050 24656 FP R/W 0 to 99.9 (0 = no soak)
Segment #16
PID SET
176 60B0 24752 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #17
Ramp Time
67 6043 24643 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #17
PID SET
177 60B1 24753 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #18
Soak Setpoint
Value
68 6044 24644 FP R/W Within Setpoint Limits
Segment #18
Soak Time
69 6045 24645 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak #18
81 6051 24657 FP R/W 0 to 99.9 (0 = no soak)
Segment #18
PID SET
178 60B2 24754 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #19
Ramp Time
70 6046 24646 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #19
PID SET
179 60B3 24755 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #20
Soak Setpoint
Value
71 6047 24647 FP R/W Within Setpoint Limits
Segment #20
Soak Time
72 6048 24648 FP R/W 99.59 (0-99
Hrs:0-59 Min)
