Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 369
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #7
Ramp Time
10 600A 24586 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #7
PID SET
147 6093 24723 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #8 Soak
Setpoint Value
11 600B 24587 FP R/W Within Setpoint Limits
Segment #8 Soak
Time
12 600C 24588 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##8
34 6022 24610 FP R/W 0 to 99.9 (0 = no soak)
Segment #8
PID SET
148 6094 24724 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #9
Ramp Time
13 600D 24589 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #9
PID SET
149 6095 24725 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #10
Soak Setpoint
Value
14 600E 24590 FP R/W Within Setpoint Limits
Segment #10
Soak Time
15 600F 24591 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##10
35 6023 24611 FP R/W 0 to 99.9 (0 = no soak)
Segment #10
PID SET
150 6096 24726 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #11
Ramp Time
16 6010 24592 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
