Modbus Read, Write and Override Parameters plus Exception Codes
370 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #11
PID SET
151 6097 24727 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #12
Soak Setpoint
Value
17 6011 24593 FP R/W Within Setpoint Limits
Segment #12
Soak Time
18 6012 24594 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##12
36 6024 24612 FP R/W 0 to 99.9 (0 = no soak)
Segment #12
PID SET
152 6098 24728 FP R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #13
Ramp Time
19 6013 24595 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #13
PID SET
153 6099 24729 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #14
Soak Setpoint
Value
20 6014 24596 FP R/W Within Setpoint Limits
Segment #14
Soak Time
21 6015 24597 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##14
37 6025 24613 FP R/W 0 to 99.9 (0 = no soak)
Segment #14
PID SET
154 609A 24730 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #15
Ramp Time
22 6016 24598 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #15
PID SET
155 609B 24731 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
