Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 371
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #16
Soak Setpoint
Value
23 6017 24599 FP R/W Within Setpoint Limits
Segment #16
Soak Time
24 6018 24600 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##16
38 6026 24614 FP R/W 0 to 99.9 (0 = no soak)
Segment #16
PID SET
156 609C 24732 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #17
Ramp Time
25 6019 24601 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #17
PID SET
157 609D 24733 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #18
Soak Setpoint
Value
26 601A 24602 FP R/W Within Setpoint Limits
Segment #18
Soak Time
27 601B 24603 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##18
39 6027 24615 FP R/W 0 to 99.9 (0 = no soak)
Segment #18
PID SET
158 609E 24734 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #19
Ramp Time
28 601C 24604 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #19
PID SET
159 609F 24735 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #20
Soak Setpoint
Value
29 601D 24605 FP R/W Within Setpoint Limits
Segment #20
Soak Time
30 601E 24606 FP R/W 99.59 (0-99
Hrs:0-59 Min)
