Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 397
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Gate 2 InputA (B
LT A or B GT A)
173 40AD 16557 INT R/W Same as ID 171
Gate 2 InputB
(OR, NOR, AND,
NAND, X OR, X
NOR)
157 409D 16541 INT R/W Same as ID 153
Gate 2 InputB (B
LT A or B GT A)
174 40AE 16558 INT R/W Same as ID 172
Logic Gate2 K
Constant
101 4065 16485 FP R/W –999.0 to +9999
Gate 3 InputA
(OR, NOR, AND,
NAND, X OR, X
NOR)
160 40A0 16544 INT R/W Same as ID 152
Gate 3 InputA (B
LT A or B GT A)
175 40AF 16559 INT R/W Same as ID 171
Gate 3 InputB
(OR, NOR, AND,
NAND, X OR, X
NOR)
161 40A1 16545 INT R/W Same as ID 153
Gate 3 InputB (B
LT A or B GT A)
176 40B0 16560 INT R/W Same as ID 172
Logic Gate3 K
Constant
102 4066 16486 FP R/W –999.0 to +9999
Gate 4 InputA
(OR, NOR, AND,
NAND, X OR, X
NOR)
164 40A4 16548 INT R/W Same as ID 152
Gate 4 InputA (B
LT A or B GT A)
177 40B1 16561 INT R/W Same as ID 171
Gate 4 InputB
(OR, NOR, AND,
NAND, X OR, X
NOR)
165 40A5 16549 INT R/W Same as ID 153
Gate 4 InputB (B
LT A or B GT A)
178 40B2 16562 INT R/W Same as ID 172
Logic Gate4 K
Constant
103 4067 16487 FP R/W –999.0 to +9999
Gate 5 InputA
(OR, NOR, AND,
NAND, X OR, X
NOR)
168 40A8 16552 INT R/W Same as ID 152
