Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
400 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
C2 Range 236 00EC 236 INT R/W 0 = 4-20 mA
1 = 0 -20 mA
Current
Output 1
242 00F2 242 INT R/W 0 = Disable
1 = Input 1
2 = Input 2
3 = Input 3
4 = Input 4
5 = Input 5
6 = PV
7 = CB Out
8 = DEV
9 = Output
10 = SP
11 = LSP
12 = RSP
13 = In Alg 1
14 = In Alg 2
15 = PV2
16 = CBOUT2
17 = DEV 2
18 = Output Loop 2
19 = SP Loop 2
20 = LSP1 Loop 2
21 = RSP Loop 2
Current
Output 1
Range
235 00EA 235 INT R/W 0 = 4-20 mA
1 = 0-20 mA
Current 1
Low Scaling
Factor
100 0064 100 FP R/W Within the range of the
selected variable in ID 242
Current 1
High Scaling
Factor
101 0065 101 FP R/W Within the range of the
selected variable in ID 242
