Modbus Read, Write and Override
Parameters plus Exception Codes
3/07
UDC3500 Universal Digital Controller Product Manual
391
Parameter
Register
Address
Data
Type
Access
Data Range or
Enumerated Selection
Description
ID
Hex
Decimal
Input Algorithm 2
Input C Selection
(used with ID 209
math
calculations)
212
00D4
212
INT
R/W
0 = None
1 = Input 1
2 = Input 2
3 = Input 3
4 = Input 4
5 = Input 5
6 = Loop 1 Output
7 = Loop 2 Output
8 = Input 1 Algorithm
9 = Input 2 Algorithm
Algorithm2Bias
93
005D
93
FP
R/W
-999.0 to 9999 in
Engineering Units
406
408
