Configuration
104 UDC3500 Universal Digital Controller Product Manual 3/07
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
GATE(n)INB
(n = 1, 2, 3, 4, or 5)
GATE (n) INPUT B—The selection here will indicate
what Input B will be for any of the 5 Gates you want
to configure.
The following selections apply if the Gate Type is
OR, NOR, AND, NAND, X OR, or X NOR.
DIG IN1
DIG IN2
DIG IN3
DIG IN4
RELAY 1
RELAY 2
RELAY 3
RELAY 4
RELAY 5
GATE1OT
GATE2OT
GATE3OT
GATE4OT
GATE5OT
FIX ON
FIX OFF
DIGITAL INPUT 1
DIGITAL INPUT 2
DIGITAL INPUT 3
DIGITAL INPUT 4
RELAY 1
RELAY 2
RELAY 3
RELAY 4
RELAY 5
OUTPUT FROM GATE 1
OUTPUT FROM GATE 2
OUTPUT FROM GATE 3
OUTPUT FROM GATE 4
OUTPUT FROM GATE 5
ALWAYS A “1”
ALWAYS A “0”
MA MODE
LR SPL1
ADAPT1
MA MOD2 *
LR SPL2 *
ADAPT 2 *
Manual or Auto mode – Loop 1
0 = Manual 1 = Automatic
Local or Remote Setpoint – Loop 1
0 = Local 1 = Remote
Disable or Enable Adaptive Tune – Loop 1
0 = Disable 1 = Enable
Manual or Auto Mode – Loop 2
0 = Manual 1 = Automatic
Local or Remote Setpoint – Loop 2
0 = Local 1 = Remote
Disable or Enable Adaptive Tune – Loop 2
0 = Disable 1 = Enable
