Configuration
3/07 UDC3500 Universal Digital Controller Product Manual 105
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
L1 PV
L1 SP
TOTALZE
L2 PV *
L2 SP *
* These prompts appear
only when 2 Loops are
configured.
The following selections apply if the Gate Type is
B LT A (B less than A) or B GT A (B greater than A).
ANALOG INPUT 1
ANALOG INPUT 2
ANALOG INPUT 3
ANALOG INPUT 4
ANALOG INPUT 5
LOOP 1 PROCESS VARIABLE
LOOP 1 SETPOINT
TOTALIZER (see Note 1)
LOOP 2 PROCESS VARIABLE
LOOP 2 SETPOINT
Note 1: The Input B Totalizer Value will be the
displayed value, not the actual Totalizer value.
GATE(n)OUT
(n = 1, 2, 3, 4, or 5)
RELAY 1
RELAY 2
RELAY 3
RELAY 4
RELAY 5
ANY GATE
MA MODE
LR SPL1
ADAPT 1
RESET T
MA MOD2 *
LR SPL2 *
ADAPT 2 *
* These prompts appear
only when 2 Loops are
configured.
GATE (n) OUTPUT—The selection here indicates
what the output will be for any of the 5 gates that you
configure.
RELAY 1
RELAY 2
RELAY 3
RELAY 4
RELAY 5
Output to any Gate
Manual or Auto mode – Loop 1
0 = Manual 1 = Automatic
Local or Remote Setpoint – Loop 1
0 = Local 1 = Remote
Disable or Enable Adaptive Tune – Loop 1
0 = Disable 1 = Enable
Disable or Enable Totalizer Reset
0 = Disable 1 = Enable
Manual or Auto Mode – Loop 2
0 = Manual 1 = Automatic
Local or Remote Setpoint – Loop 2
0 = Local 1 = Remote
Disable or Enable Adaptive Tune – Loop 2
0 = Disable 1 = Enable
