Configuration
3/07 UDC3500 Universal Digital Controller Product Manual 125
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
SLIDEW
TC DIFF
SW EMUL
PR
SLIDEWIRE—Slidewire for Position Proportional
TC DIFF—Thermocouple Differential
SLIDEWIRE EMULATION—Herculine Slidewire
Emulation
PR—PR40-PR20 Thermocouple
XMITTER3
B TC
E TC H
E TC L
J TC H
J TC M
J TC L
K TC H
K TC M
K TC L
NNM H
NNM L
NIC H
NIC L
PLAT H
PLAT L
R TC
S TC
T TC H
T TC L
W TC H
W TC L
100 PT
100 LO
200 PT
500 PT
RAD RH
RAD RI
LINEAR
SQROOT
TRANSMITTER 3 CHARACTERIZATION—This
selection lets you instruct the controller to
characterize a linear input to represent a non-linear
one.
ATTENTION Prompt only appears when a linear
actuation is selected at prompt IN3 TYPE.
FOR EXAMPLE:
If Input 3 is a 4 to 20 mA signal, but the signal
represents a type K thermocouple, then select K TC
H and the controller will characterize the 4 to 20 mA
signal so that it is treated as a type K thermocouple
input (high range).
Parameter definitions are the same as in IN3 TYPE.
IN3 HIGH
–999. To 9999. Floating
(in engineering units)
INPUT 3 HIGH RANGE VALUE—This value in
engineering units is displayed for all inputs but can
only be changed for inputs configured for linear or
square root transmitter characterization.
See the example in IN1 HI.
IN3 LOW
–999. To 9999. Floating
(in engineering units)
INPUT 3 LOW RANGE VALUE—This value in
engineering units is displayed for all inputs but can
only be changed for inputs configured for linear or
square root transmitter characterization.
See the example in IN1 HI
RATIO 3
–20.00 to 20.00
Floats to 3 decimal places
RATIO ON INPUT 3—Select the Ratio value you
want on Input 3.
BIAS IN3
–999. to 9999.
(in engineering units)
BIAS ON INPUT 3—Bias is used to compensate the
input for drift of an input value due to deterioration of
a sensor, or some other cause. Select the bias value
you want on Input 3.
Final Input 3 Value = Input 3 * Ratio 3 + Bias 3
FILTER 3
0 to 120 seconds
No filter = 0
FILTER FOR INPUT 3—A software digital filter is
provided for Input 3 to smooth the input signal. You
can configure the first order lag time constant from 1
to 120 seconds. If you do not want filtering, enter 0.
