Configuration
3/07
UDC3500 Universal Digital Controller Product Manual
187
Group Prompt
Function Prompt
Value or Selection
Factory Setting
8SEG CH1
DISABLE
X1 VALUE
0
X2 VALUE
0
X3 VALUE
0
X4 VALUE
0
X5 VALUE
0
X6 VALUE
0
X7 VALUE
0
X8 VALUE
0
Y1 VALUE
0
Y2 VALUE
0
Y3 VALUE
0
Y4 VALUE
0
Y5 VALUE
0
Y6 VALUE
0
Y7 VALUE
0
Y8 VALUE
0
8 SEG CH2
DISABLE
X9 VALUE
0
X10 VALUE
0
X11 VALUE
0
X12 VALUE
0
X13 VALUE
0
X14 VALUE
0
X15 VALUE
0
X16 VALUE
0
X17 VALUE
0
Y9 VALUE
0
Y10 VALUE
0
Y11 VALUE
0
Y12 VALUE
0
Y13 VALUE
0
Y14 VALUE
0
Y15 VALUE
0
Y16 VALUE
0
Y17 VALUE
0
TOTALIZE
DISABLE
Σ
XXXXXXX
-
-
TOT SCALE
E0
TOT SCR
UNLOCK
Σ
RESET?
NO
TOT RATE
SECOND
POLYNOM
DISABLE
C0 VALUE
0
C1 VALUE
0
C2 X 10
-1
0
C2 X 10
-3
0
C2 X 10
-5
0
MATH
C2 X 10
-7
0
202
