Monitoring and Operating the Controller
256
UDC3500 Universal Digital Controller Product Manual
3/07
Table 4-34 Program #3 Record Sheets
Prompt
Function
Segment
Value
Prompt
Function
Segment
Value
SG11RA
MP
Ramp Time
11
SG17RAMP
Ramp Time
17
SG11 PID
PID Set
11
SG17 PID
PID Set
17
SG12 SP
Soak SP
12
SEG18 SP
Soak SP
18
SG12TIME
Soak Time
12
SG18TIME
Soak Time
18
SOA
K12DV
Guar. Soak
12
SOA
K18DV
Guar. Soak
18
SG12 PID
PID Set
12
SG18 PID
PID Set
18
SG13RA
MP
Ramp Time
13
SG19RA
MP
Ramp Time
19
SG13 PID
PID Set
13
SG19 PID
PID Set
19
SEG14 SP
Soak SP
14
SEG20 SP
Soak SP
20
SG14TIME
Soak Time
14
SG20TIME
Soak Time
20
SOA
K14DV
Guar. Soak
14
SOA
K20DV
Guar. Soak
20
SG14 PID
PID Set
14
SG20 PID
PID Set
20
SG15RA
MP
Ramp Time
15
SG15 PID
PID Set
15
SEG16 SP
Soak SP
16
SG16TIME
Soak Time
16
SOA
K16DV
Guar. Soak
16
SG16 PID
PID Set
16
271
273
