Honeywell UDC3500 User Manual

Modbus Read, Write and Override Parameters plus Exception Codes
3/07 UDC3500 Universal Digital Controller Product Manual 365
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #13
Ramp Time
72 4048 16456 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #13
PID SET
203 40CB 16587 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #14
Soak Setpoint
Value
73 4049 16457 FP R/W Within Setpoint Limits
Segment #14
Soak Time
74 404A 16458 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##14
93 405D 16477 FP R/W 0 to 99.9 (0 = no soak)
Segment #14
PID SET
204 40CC 16588 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #15
Ramp Time
75 404B 16459 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #15
PID SET
205 40CD 16589 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #16
Soak Setpoint
Value
76 404C 16460 FP R/W Within Setpoint Limits
Segment #16
Soak Time
77 404D 16461 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##16
94 405E 16478 FP R/W 0 to 99.9 (0 = no soak)
Segment #16
PID SET
206 40CE 16590 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #17
Ramp Time
78 404E 16462 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
