Modbus Read, Write and Override Parameters plus Exception Codes
364 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Segment #8
PID SET
198 40C6 16582 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #9
Ramp Time
0045 069 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #9
PID SET
199 40C7 16583 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #10
Soak Setpoint
Value
70 0046 070 FP R/W Within Setpoint Limits
Segment #10
Soak Time
71 0047 071 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##10
91 405B 16475 FP R/W 0 to 99.9 (0 = no soak)
Segment #10
PID SET
200 40C8 16584 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #11
Ramp Time
72 0048 072 FP R/W 99.59 (0-99
Hrs:0-59 Min) or
0 to 999
(Degrees/Minute)
Segment #11
PID SET
201 40C9 16585 INT R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
Segment #12
Soak Setpoint
Value
73 0049 073 FP R/W Within Setpoint Limits
Segment #12
Soak Time
74 004A 074 FP R/W 99.59 (0-99
Hrs:0-59 Min)
Guaranteed
Soak ##12
92 405C 16476 FP R/W 0 to 99.9 (0 = no soak)
Segment #12
PID SET
202 40CA 16586 FP R/W 0 = SET1
1 = SET2
2 = SET3
3 = SET4
