Modbus Read, Write and Override Parameters plus Exception Codes
418 UDC3500 Universal Digital Controller Product Manual 3/07
Parameter Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Description ID Hex Decimal
Current Output 3 246 00F6 246 INT R/W 0 = None
1 = Input 1
2 = Input 2
3 = Input 3
4 = Input 4
5 = Input 5
6 = PV
7 = CB OUT
8 = Dev
9 = Out
10 = SP
11 = LSP 1
12 = RSP
13 = Input ALG 1
14 = Input ALG 2
15 = PV 2
16 = CBOUTL2
17 = DEV2
18 = Output Loop 2
19 = SP Loop 2
20 = LSP1 Loop 2
21 = RSP Loop 2
Current Output 3
Low Scaling
Factor
86 0056 86 FP R/W Within the range of the
selected variable in ID 246
Current Output 3
High Scaling
Factor
87 0057 87 FP R/W Within the range of the
selected variable in ID 134
Current Output 3
Range
247 00F7 247 INT R/W 0 = 4-20 mA
1 = 0-20 mA
