Honeywell UDC3500 - 3.11 Algorithm Set Up Group

Configuration
62 UDC3500 Universal Digital Controller Product Manual 3/07
Function Prompt
Lower Display
Selections or
Range of Setting
Upper Display
Parameter
Definition
RERUN
RERUN CURRENT CYCLE—When enabled, this
selection allows you to reset the program via the
keyboard to the beginning of the current cycle. The
Recycle value is not affected. The program mode
(RUN or HOLD) is not affected.
HOTSTART
DISABLE
ENABLE
HOT START—This feature allows the SP Program to
start at the current PV value rather than the current
Setpoint value.
SEG1RAMP or
SEG1RATE
0-99 hours.0-59 minutes
Engineering units/minute
or
Engineering units/hour
Segment #1 Ramp Time or
Segment #1 Ramp Rate
ATTENTION This parameter is affected by the
RAMPUNIT configuration (see above). All ramps will
use the same selection.
SEG1PID
1-4
PID Set Selection
ATTENTION The PID Set Selection prompts will
only show up when PID SETS in the Control 1 or
Control 2 Setup Group is set to 4 KEYBD. See
Section
3.20 (Control 1) and Section 3.21 (Control 2).
SEG2 SP
Within the Setpoint limits
Segment #2 Soak Setpoint Value
SEG2TIME
0-99 hours.0-59 minutes
Segment #2 Soak Duration
SOAK2DEV
0.000 to 99.99
Guaranteed Soak Deviation Value For Soak
Segment #2—The number selected will be the PV
value (in engineering units) above and below the
setpoint outside of which the Soak Segment timer
halts. A value of 0.000 is equivalent to no Guaranteed
Soak.
SEG2 PID
1-4
PID Set Selection—This selection is Loop
dependent.
ATTENTION The PID Set Selection prompts will
only show up when PID SETS in the Control 1 or
Control 2 Setup Group is set to 4 KEYBD. See
Section
3.20 (Control 1) and Section 3.21 (Control 2).
SEG3RAMP or
SEG3RATE
SEG3 PID
SEG4 SP
SEG4TIME
SOAK4DEV
SEG4 PID
SEG5RAMP or
SEG5RATE
SEG5 PID
SEG6 SP
SEG6TIME
Selections are same as
above.
Same as above
