FusionModule2000 Smart Modular Data Center
Installation Guide
15 Installing Monitoring Devices
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 15-26 Installing an inner cover
Step 6 Install the front cover of the camera in the direction shown in Figure 15-27, and tighten the
screws on the front cover.
Remove the protective film from the transparent cover.
Figure 15-27 Installing a front cover
----End
