FusionModule2000 Smart Modular Data Center
Installation Guide
16 (Optional) Installing In-Room Access Control
Devices and Cameras
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Pay attention to the direction of the hoisting strip, and ensure that the bulging surface of the
magnetic lock faces the magnet.
Figure 16-15 Installing a magnetic lock
Step 5 Remove the small cover from the magnetic lock, and route the cable out of the cable hole, as
shown in Figure 16-16.
Figure 16-16 Connecting cables
