JUMO LOGOSCREEN 601 User Manual

7 Configuration
106
Customer-specific 1 to 4 Customer-specific linearization using
grid points (pairs of values) or 4th order
polynomial
Resistance mea-
suring range
Measuring range for resistance/potentiometer and for customer-specific lineariza-
tion with RTD temperature probe
0 to 4000 Ω
0 to 400 Ω
Measuring range
start
-99999 to +99999
(Default setting depends on sensor and
linearization.)
Lower limit of measuring range (for volt-
age/current signal, resistance/potenti-
ometer, or resistance transmitter)
If the measured value is below the lower
limit, "<<<<<" (out of range) is shown for
a numerical display.
Measuring range
end
-99999 to +99999
(Default setting depends on sensor and
linearization.)
Upper limit of measuring range (for volt-
age/current signal, resistor/potentiome-
ter, or resistance transmitter)
If the measured value is above the upper
limit, ">>>>>" (out of range) is shown for
a numerical display.
Scaling
start
-99999 to +99999
(Default setting depends on sensor and
linearization.)
Lower limit of measuring range or display
range (depending on sensor and linear-
ization)
Scale
end
-99999 to +99999
(Default setting depends on sensor and
linearization.)
Upper limit of measuring range or display
range (depending on sensor and linear-
ization)
Decimal places Number of pre-decimal and decimal places for the numerical display of the mea-
sured value
Even if the number of decimal places is fixed, the format is automatically changed
if needed in order to display all digits before the decimal point.
Auto Automatic
XXXXXp No decimal place
XXXXpX One decimal place
XXXpXX Two decimal places
XXpXXX Three decimal places
XpXXXX Four decimal places
Offset -99999 to 0 to +99999 Correction value
Filter time con-
stant
0 s to 1 s to 100 s Time constant for adjusting the digital in-
put filter (0 s = filter off)
Compensation Selection of cold junction (for thermocouple)
Internal Pt100 Internal Pt100 temperature probe
External constant Constant cold junction temperature
Ext. reference
temperature
-30 to 0 to +85 Cold junction temperature (for thermo-
couple and constant cold junction tem-
perature)
