7 Configuration
136
Additional
storage
The parameter decides whether the current statuses are to be saved additionally
(in addition to the save operation resulting from the "Type" parameter). The current
statuses are saved but not reset. Depending on the specific setting (Yes - No), the
parameters from the previous chapter "General settings" must also be taken into
consideration.
The parameter is only active for "Save (for evaluation)" = Yes.
Inactive No additional storage
Periodically Completion and restart will be deter-
mined by the "Period" and "Synch. time"
parameters.
Daily The counter/integrator is counted/inte-
grated for a day (24 hours). Completion
and restart will be determined by the
"Synch. time" parameter.
Weekly The counter/integrator is counted/inte-
grated for a week. Completion and re-
start will be determined by the "Day of
the week" and "Synch. time" parameters.
Monthly The counter/integrator is counted/inte-
grated for a month. Completion and re-
start are performed on the first day of the
month at 00:00.
Annual The counter/integrator is counted/inte-
grated for a year. Completion and restart
are performed on the first day of the year
at 00:00.
Signal source Analog selector and digital selector
No selection
Input signal to be counted (digital signal)
or integrated (analog signal).
For the "Flow (total)" function, the flow
process value is used as the signal
source.
For the "High-speed counter" function,
digital input/output 1 is used as the signal
source.
Factor "Counter" and "High-speed counter" function: The counter status is incremented by
the factor value for each digital signal pulse. A negative value can be used to form
a backwards counter.
"Integrator" function: The current measured value of the analog or integer signal is
multiplied by the factor and added to the result.
-99999 to 1 to +99999 Value or factor
Parameter Selection/settings Description
