5 Operation
Horizontal diagram
In the horizontal diagram, the analog curves and digital traces run from right to left. The channel infor-
mation is shown on the right edge of the screen; the icons for event and alarm at the top edge of the
screen.
Digital traces and channel information can be hidden in the group configuration, as in the vertical view.
