Lexmark MS821 Service Manual

245 paper jams
245 paper jam messages
Error code Description Action
245.56 Paper fed from tray 5 was picked but it never
reached the sensor (tray 4 pass‑through).
See
“Tray 5 pick jam service check” on
page 183.
245.70 Motor (2100‑sheet tray 5 elevator) does not turn
on.
See
“2100‑sheet tray elevator drive jam service
check” on page 152.
245.71 Motor (2100‑sheet tray 5 elevator) does not turn
o.
245.72 Motor (2100‑sheet tray 5 elevator) speed did not
ramp up to the required level.
245.73 Motor (2100‑sheet tray 5 elevator) stalled.
245.74 Motor (2100‑sheet tray 5 elevator) ran too slow.
245.75 Motor (2100‑sheet tray 5 elevator) ran too fast.
245.76 Motor (2100‑sheet tray 5 elevator) ran too long.
245.80 Motor (tray 5 pick/lift) does not turn on. See
“Optional tray pick drive failure service
check” on page 324.
245.81 Motor (tray 5 pick/lift) does not turn o.
245.82 Motor (tray 5 pick/lift) speed did not ramp up to
the required level.
245.83 Motor (tray 5 pick/lift) stalled.
245.84 Motor (tray 5 pick/lift) ran too slow.
245.85 Motor (tray 5 pick/lift) ran too fast.
245.86 Motor (tray 5 pick/lift) moved too long.
245.91 Paper remains detected at the sensor (tray 5
pass‑through) after the printer is turned on.
See
“Sensor (tray 5 pass‑through) static jam
service check” on page 181.
Sensor (tray 5 pass‑through) static jam service check
Action Yes No
Step 1
Check the paper path and trays for paper fragments and partially
fed paper.
Is the paper path free of paper fragments and partially fed paper?
Go to step 3. Go to step 2.
Step 2
Remove the paper fragments and partially fed paper.
Does the problem remain?
Go to step 3. The problem is
solved.
4064
Diagnostics and troubleshooting
181

Lexmark MS821 Specifications

General

USB connector	USB Type-A / USB Type-B
Direct printing	Yes
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	2
Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4.5 s
Print speed (black, normal quality, A4/US Letter)	52 ppm
Display	LCD
Certification	ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55024, UL), EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532B, ECMA-370, TED, GOST-R, SII, TER
Product color	Black, White
Display diagonal	2.4 \
Market positioning	Enterprise
Power consumption (ready)	39 W
Power consumption (printing)	670 W
Energy Star Typical Electricity Consumption (TEC)	2.1 kWh/week
Country of origin	China
Maximum duty cycle	250000 pages per month
Recommended duty cycle	3000 - 50000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3, XPS
Internal memory	512 MB
Processor frequency	1000 MHz
Maximum internal memory	4608 MB
Sound pressure level (printing)	57 dB
Sound pressure level (duplex printing)	56 dB
Mac operating systems supported	Mac OS X 10.1 Puma, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	Fedora 23, Fedora 24, Fedora 25, Fedora 26, Fedora 27, RedHat EL Linux 7.0, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, openSUSE 13.2, openSUSE 42.3
Server operating systems supported	SUSE Linux Enterprise Server 10, SUSE Linux Enterprise Server 11, SUSE Linux Enterprise Server 12
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Paper input type	Paper tray
Total input capacity	550 sheets
Maximum input capacity	4400 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Envelopes, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Sustainability certificates	Blue Angel, ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	650 mm
Package width	550 mm
Package height	565 mm
Package weight	29900 g
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, IPSEC, LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, TTLS, HTTPS, SNMP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Cables included	AC

Weight and Dimensions

Depth	510 mm
Width	428 mm
Height	445 mm
Weight	25400 g
