Mailbox controller board removal
1 Remove the mailbox top cover. See “Mailbox top cover removal” on page 648.
2 Remove the mailbox left cover. See “Mailbox left cover removal” on page 654.
3 Disconnect all cables (J1B, J5, J4D, J2A, J4C, J2B, J4B, J2C, J4A, J8, J1A, J3B, J7, J6, J12, and J3T), and
then remove the two screws (A) from the controller board.
4064
Parts removal
667
