Lexmark MS821

4 Disconnect the cable (A), and then release the sensor latches (B).
5 Remove the sensor.
Mailbox lower interface cable removal
1 Remove the mailbox top cover. See “Mailbox top cover removal” on page 648.
2 Remove the mailbox left cover. See “Mailbox left cover removal” on page 654.
4064
Parts removal
670
