Lexmark MS821

Sensor (2100-sheet tray A5 length guide) removal
1 Remove the 2100-sheet tray insert. See “2100-sheet tray insert removal” on page 472.
2 Remove the screw (A), and then disconnect the sensor cable (B).
3 Remove the sensor.
Sensor (2100-sheet tray pick roller index) removal
1 Remove the 2100-sheet tray insert. See “2100-sheet tray insert removal” on page 472.
2 Remove the 2100-sheet tray pick roller.
4064
Parts removal
491
