Lexmark MS821

Sensor (staple finisher diverter plunger) removal
1 Remove the staple
finisher
left cover. See “Staple
finisher
left cover removal” on page 584.
2 Remove the screw (A), and then disconnect the cable (B).
3 Remove the sensor.
Motor (staple
finisher
transport) removal
1 Remove the staple finisher left cover. See “Staple finisher left cover removal” on page 584.
2 Remove the staple finisher interface cable. See “Staple finisher interface cable removal” on page 595.
4064
Parts removal
599
