• Allow the following recommended amount of space around the printer for proper ventilation:
1 Top 1 52 m m (6 in.)
2 Right side 152 mm (6 in.)
3 Front 406 mm (16 in.)
Note: The minimum space needed in front of the printer is 76 mm (3 in.).
4 Left side 152 mm (6 in.)
5 Rear 152 mm (6 in.)
Noise emission levels
The following measurements were made in accordance with ISO 7779 and reported in conformance with ISO
9296.
Note: Some modes may not apply to your product.
1-meter average sound pressure, dBA
Printing 56 (MS725dvn); 57 (B2865dw,
M5255, MS821n, MS821dn,
MS822de, MS823n, MS823dn); 58
(M5270, MS825dn, MS826de)
Ready 28 (MS725dvn); 14 (B2865dw, M5255,
M5270, MS821n, MS821dn, MS822de,
MS823n, MS823dn, MS825dn,
MS826de)
Values are subject to change. See www.lexmark.com for current values.
4064
Printer specifications
