Lexmark MS821

Transport drive
1 Feed path
2 Pass‑through path
3 Motor (transport)
The pass‑through path is where paper that is fed from lower trays passes over to the upper trays and into the
printer. The motor (transport) drives the transport rollers that move the papers in this path.
The feed path is where paper from the source tray passes over to the pass‑through path of the upper tray.
4064
Theory of operation
886
