Lexmark MS821

Staple, hole punch finisher latch removal
1 Remove the staple, hole punch
finisher
left cover or right cover. See “Staple, hole punch
finisher
left cover
removal” on page 699 or “Staple, hole punch finisher right cover removal” on page 701.
2 Pull the latch o the finisher.
Note: The latch on the right side can be removed using the same method shown.
Sensor (SHPF paddle) removal
1 Remove the staple, hole punch
finisher
left cover. See “Staple, hole punch
finisher
left cover removal” on
page 699.
2 Remove the staple, hole punch finisher right cover. See “Staple, hole punch finisher right cover removal”
on page 701.
3 Remove the staple, hole punch
finisher
top cover. See “Staple, hole punch
finisher
top cover removal” on
page 703.
4064
Parts removal
737
