SF paper path rollers
1 Staple finisher entrance rollers
2 Staple finisher exit rollers
3 Staple finisher paddle rollers
For staple jobs, the paper path is redirected to the finisher.
Before stapling occurs, paper is stacked on top of each other and aligned along its edges.
When the staple job is done, the paper is ejected to the bin.
4064
Theory of operation
