Optional staple, hole punch finisher operation
Staple, hole punch finisher (SHPF) layout
457 3
2
1
6
1 Hole punch box
2 Hole punch unit
3 Staple unit
4 Paddle and exit
5 Tamper
6 Ejector
7 Bin
4064
Theory of operation
900
