4 Disconnect the cable (A), and then remove the two screws (B).
5 Remove the motor.
Tamper drive belt removal
1 Remove the staple
finisher
left cover. See “Staple
finisher
left cover removal” on page 584.
2 Remove the staple finisher right cover. See “Staple finisher right cover removal” on page 586.
3 Remove the staple
finisher
top cover. See “Staple
finisher
top cover removal” on page 588.
4 Release the motor engaged to the belt. See “Motor (staple finisher right tamper) removal” on page 619
or
“Motor (staple finisher left tamper) removal” on page 619.
