Action Yes No
Step 6
a Remove the output expander left cover. See “Output expander
left cover removal” on page 522.
b Reseat the cable on the motor (OE diverter) and on the output
expander controller board.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Check the motor (OE diverter) for improper installation and
damage.
Is the motor properly installed and free of damage?
Go to step 9. Go to step 8.
Step 8
Reinstall or replace the motor. See
“Motor (OE diverter) removal”
on page 529.
Does the problem remain?
Go to step 9. The problem is
solved.
Step 9
Reseat the cable on the sensor (OE diverter plunger) and on the
output expander controller board.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
Check the sensor for improper installation, contamination, and
damage.
Is the sensor properly installed and free of contamination and
damage?
Go to step 12. Go to step 11.
Step 11
Reinstall or replace the sensor. See
“Sensor (OE diverter plunger)
removal” on page 536.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 12
Check the output expander diverter plunger for improper
installation and damage.
Is the diverter plunger properly installed and free of damage?
Go to step 14. Go to step 13.
Step 13
Reinstall or replace the diverter plunger. See
“Output expander
diverter plunger assembly removal” on page 529.
Does the problem remain?
Go to step 14. The problem is
solved.
