Action Yes No
Step 6
a Enter the Diagnostics menu, and then navigate to:
Output device adjustments/tests > Output device sensor
tests > Output expander [x]
Note: [x] is the number of the
aected
bin.
b Find the sensor (Pass-through).
Does the sensor status change while toggling the sensor?
Go to step 10. Go to step 7.
Step 7
a Remove the output expander left cover. See “Output expander
left cover removal” on page 522.
b Reseat the sensor cable on the output expander controller
board.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Check the sensor for improper installation, contamination, and
damage.
Is the sensor properly installed and free of contamination and
damage?
Go to step 10. Go to step 9.
Step 9
Reinstall or replace the sensor. See
“Sensor (OE pass‑through)
removal” on page 542.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
Enter the Diagnostics menu, and then navigate to:
Output bin quick feed
Perform the feed test on each optional bin.
Does the error occur in any of the optional bins?
Go to step 12. Go to step 11.
Step 11
a Remove the optional bins.
b Reinstall the optional bins one at a time, and then identify which
bin is causing the error.
Does the error occur in any of the optional bins?
Go to step 12. Contact the next
level of support.
4064
Diagnostics and troubleshooting
190
