Action Yes No
Step 5
a Enter the Diagnostics menu, and then navigate to:
Output bin quick feed > Feed to all bins
b To uc h Single or Continuous.
Does the problem remain?
Go to step 6. The problem is
solved.
Step 6
a Remove the staple finisher left cover. See “Staple finisher left
cover removal” on page 584.
b Reseat the cable on the sensor (staple finisher diverter plunger)
and on the staple finisher controller board.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Check the sensor for improper installation, contamination, and
damage.
Is the sensor properly installed and free of contamination and
damage?
Go to step 9. Go to step 8.
Step 8
Reinstall or replace the sensor. See
“Sensor (staple finisher
diverter plunger) removal” on page 599.
Does the problem remain?
Go to step 9. The problem is
solved.
Step 9
Reseat the cable on the motor (staple finisher diverter) and on the
staple finisher controller board.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
Check the motor (staple finisher diverter) for improper installation
and damage.
Is the motor properly installed and free of damage?
Go to step 12. Go to step 11.
Step 11
Reinstall or replace the motor. See
“Motor (staple finisher
diverter) removal” on page 598.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 12
Check the staple finisher diverter plunger for improper installation
and damage.
Is the diverter plunger properly installed and free of damage?
Go to step 14. Go to step 13.
4064
Diagnostics and troubleshooting
245
