Error
code
Description Action
431.13 The bin 1 elevator bin did not reach the
sensor (SHPF elevator, top) on time.
See
“SHPF elevator top jam service check” on page 268.
431.15 The bin 1 elevator bin did not clear the
sensor (SHPF elevator, top) on time.
431.23 The bin 2 elevator bin did not reach the
sensor (SHPF elevator, top) on time.
431.25 The bin 2 elevator bin did not clear the
sensor (SHPF elevator, top) on time.
431.54 The bin 1 motor (SHPF elevator) did not
reach the required speed.
431.55 The bin 1 motor (SHPF elevator) went over
the required speed.
431.64 The bin 2 motor (SHPF elevator) did not
reach the required speed.
431.65 The bin 2 motor (SHPF elevator) went
over the required speed.
432.13 The bin 1 left stapler head did not reach
its home position.
See
“SHPF left staple jam service check” on page 270.
432.15 The bin 1 left stapler head did not clear its
home position.
432.23 The bin 2 left stapler head did not reach
its home position.
432.25 The bin 2 left stapler head did not clear
its home position.
433.13 Paper going to bin 1 did not reach the left
sensor (SHPF staple throat paper
present) on time.
See
“SHPF left staple throat jam service check” on
page 272.
433.14 Paper going to bin 1 cleared the left
sensor (SHPF staple throat paper
present) earlier than expected.
433.15 Paper going to bin 1 did not clear the left
sensor (SHPF staple throat paper
present) on time.
433.23 Paper going to bin 2 did not reach the left
sensor (SHPF staple throat paper
present) on time.
433.24 Paper going to bin 2 cleared the left
sensor (SHPF staple throat paper
present) earlier than expected.
433.25 Paper going to bin 2 did not clear the left
sensor (SHPF staple throat paper
present) on time.
4064
Diagnostics and troubleshooting
265
