Action Yes No
Step 5
a Enter the Diagnostics menu, and then navigate to:
Output bin quick feed > Feed to all bins
b To uc h Single or Continuous.
Does the problem remain?
Go to step 6. The problem is
solved.
Step 6
a Remove the staple finisher left cover. See “Staple finisher left
cover removal” on page 584.
b Reseat the cable on the motor (staple finisher stack height) and
on the staple finisher controller board.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Check the staple finisher stack height assembly and its motor for
improper installation and damage.
Is the stack height assembly properly installed and free of damage?
Go to step 9. Go to step 8.
Step 8
Reinstall or replace the stack height assembly. See
“Staple finisher
stack height assembly removal” on page 629.
Does the problem remain?
Go to step 9. The problem is
solved.
Step 9
Reseat the cable on the sensor (staple finisher stack height) and
on the staple finisher controller board.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
Check the sensor for improper installation, contamination, and
damage.
Is the sensor properly installed and free of contamination and
damage?
Go to step 12. Go to step 11.
Step 11
Reinstall or replace the sensor.
Does the problem remain?
Go to step 12. The problem is
solved.
Step 12
Make sure that the controller board of the aected optional bin is
properly installed. Reseat all the cables on the controller board.
Does the problem remain?
Go to step 13. The problem is
solved.
4064
Diagnostics and troubleshooting
275
