Action Yes No
Step 6
a Remove the staple finisher left cover. See “Staple finisher left
cover removal” on page 584.
b Reseat the staple finisher interface cable on the controller
board.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
a Remove the staple finisher. See “Optional staple finisher
removal” on page 581.
b Check the connector and pins of the staple finisher interface
cable for damage.
c Check the staple finisher interface cable for improper
installation.
Is the interface cable properly installed and free of damage?
Go to step 9. Go to step 8.
Step 8
Reinstall or replace the interface cable. See
“Staple finisher
interface cable removal” on page 595.
Does the problem remain?
Go to step 9. The problem is
solved.
Step 9
Make sure that the controller board of the aected optional bin is
properly installed. Reseat all the cables on the controller board.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
Check the aected controller board and its connector pins for
damage.
Are the bin controller board and its connectors free of damage?
Contact the next
level of support.
Go to step 11.
Step 11
Replace the bin controller board. See
“Staple finisher controller
board removal” on page 590.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
4064
Diagnostics and troubleshooting
277
