Action Yes No
Step 6
a Remove the staple finisher left cover. See “Staple finisher left
cover removal” on page 584.
b Reseat the staple finisher ejector assembly cable on the staple
finisher
controller board.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Reseat the cable of the sensor (staple finisher ejector) on the staple
finisher controller board.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Check the sensor (staple finisher ejector) for improper installation,
contamination, and damage.
Is the sensor properly installed and free of contamination and
damage?
Go to step 10. Go to step 9.
Step 9
Reinstall or replace the sensor. See
“Sensor (staple finisher
ejector) removal” on page 640.
Does the problem remain?
Go to step 10. The problem is
solved.
Step 10
a Enter the Diagnostics menu, and then navigate to:
Output bin quick feed > Feed to all bins
b To uc h Single or Continuous.
Does the staple finisher ejector assembly operate properly?
Go to step 13. Go to step 11.
Step 11
Check the ejector assembly for damage.
Is the ejector assembly free of damage?
Go to step 13. Go to step 12.
Step 12
Replace the staple finisher ejector assembly. See
“Staple finisher
ejector assembly removal” on page 637.
Does the problem remain?
Go to step 13. The problem is
solved.
Step 13
Make sure that the controller board of the aected optional bin is
properly installed. Reseat all the cables on the controller board.
Does the problem remain?
Go to step 14. The problem is
solved.
4064
Diagnostics and troubleshooting
369
