Connector Connects to Pin no. Signal
J60 Fuser, Sensor (fuser exit), Sensor
(narrow media)
1 Paper Sensor - Narrow Media
2GND
3 Main Thermistor Signal
4Belt Fuser ID Signal
5Edge Thermistor Signal
6 +5V Supply Voltage
7 Back-up Roll Thermistor Signal
8Paper Sensor - Fuser Exit
9 +3.3V Supply Voltage
10 Smart Chip Clock Signal
11 Smart Chip Data
12 Fuser Present Signal
13 GND
14 not used
J66 Optional bin, Sensor (toner smart chip),
Sensor (toner low), Motor (redrive),
Sensor (rear door interlock), Sensor
(standard bin full)
1 Motor (redrive)—Motor Encoder LED supply V
2 Optional bin—+25V Supply Voltage
3 Motor (redrive)—Motor Encoder Signal
Feedback
4 Optional bin—GND
5 Motor (redrive)—GND
6 Optional bin—
7 Motor (redrive)—Motor -V supply
8 Optional bin—Option Comm. Receive Signal
9 Motor (redrive)—Motor +V supply
10 Optional bin—Option Comm. Transmit Signal
4064
Component locations
