Lexmark MS821

Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1054 2 1 Top cover with static
brush
“Top cover removal” on page 455
241X1055 2 1Paper stacking bail --
3 41X1114 1 1 Printhead access cover “Printhead removal” on page 455
441X1632 1 1Bin cover
“Bin cover removal” on page 461
5 41X1146 1 1 Bin extender --
641X1059 1 1Trim cover --
7 41X1126 1 1 Rear door
“Rear door removal” on page 449
841X1065 1 1Rear cover
“Rear cover removal” on page 450
941X1066 1 1Right cover
“Right cover removal” on page 420
10 41X1128 1 1 Controller board access
door
“Controller board access door
removal” on page 423
11 41X1064 1 1 Inner right cover
“Inner right cover removal” on
page 436
12 41X1070 1 1 Front door
“Front door removal” on page 434
13 41X1154 2 2 Front door pins
“Front door removal” on page 434
14 41X1069 1 1 Front door bracket
“Front door bracket removal” on
page 431
15 41X1068 1 1 Inner left cover
“Inner left cover removal” on page
435
16 41X1067 1 1 Left cover
“Left cover removal” on page 409
17 41X1063 1 1 Printhead access cover
(hot roller)
“Printhead removal” on page 455
18 41X1643 2 2 Front door pivot --
4064
