Lexmark MS821

Assembly 4: Electronics 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1076 1 1 Transfer roller
“Transfer roller removal” on page
447
2 41X1077 1 1 Sensor (toner density)
“Sensor (toner density) removal” on
page 448
3 41X1095 1 1 Sensor (input)
“Sensor (input) removal” on page
440
4 41X1093 1 1 Sensor (tray 1 pick)
“Sensor (tray 1 pass‑through)
removal” on page 468
541X1094 1 1Sensor (pass‑through)
“Sensor (tray 1 pick) removal” on
page 469
6 41X1086 1 1 Optional tray interface
cable
--
7 41X1097 1 1 AC power socket
“AC power socket removal” on
page 410
8 41X1177 1 1 Fan, 80 mm
“Main fan removal” on page 412
9 41X1112 1 1 LVPS
“LVPS removal” on page 414
10 41X2356 1 1 USB host cable --
11 41X2673 1 1 Transfer roller contact
“Transfer roller contact removal” on
page 453
4064
Parts catalog
776
