Lexmark MS821

Assembly 5: Motors
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1079 1 1 Aligner
“Aligner removal” on page 439
2 41X2135 1 1 Aligner spring --
3 41X1081 1 1 Aligner screw --
441X2123 1 1Gear cover
“Optional tray drive gear removal” on
page 466
5 41X1615 1 1 Optional tray drive gear
“Optional tray drive gear removal” on
page 466
6 41X1105 1 1 Motor (MPF)
“Motor (MPF) removal” on page 413
7 41X1102 1 1 Main motor drive
“Main motor drive removal” on
page 410
8 41X1104 1 1 Fuser drive gears
“Fuser drive gears removal” on
page 412
9 41X1103 1 1 Toner cartridge drive --
10 41X2610 1 4 Guide roller --
11 41X2355 1 1 Toner cartridge motor
cable
--
12 41X1096 1 1 Motor (redrive)
“Motor (redrive) removal” on page
417
13 41X1109 1 1 Upper redrive
“Upper redrive removal” on page 453
4064
Parts catalog
778
