Lexmark MS821

Assembly 6: Sensors 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1083 1 1 Sensor (front door
interlock)
--
2 41X1083 1 1 Sensor (toner cartridge
shutter)
“Sensor (toner cartridge shutter)
removal” on page 430
3 41X1089 1 1 Toner cartridge shutter
actuator
“Toner cartridge shutter actuator
removal” on page 430
4 41X1083 1 1 Sensor (duplex interlock)
“Sensor (duplex interlock) removal”
on page 438
5 41X1083 1 1 Sensor (MPF paper
present)
--
6 41X1084 1 1 Sensor (toner smart chip)
“Sensor (toner smart chip) removal”
on page 418
7 41X2124 1 1 Toner smart chip spring
“Sensor (toner smart chip) removal”
on page 418
8 41X1072 1 1 Sensor (toner low)
“Sensor (toner low) removal” on
page 446
941X2353 1 1Toner low sensor cable--
4064
Parts catalog
780
