Lexmark MS821

Assembly 7: Sensors 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1056 1 1 Bin full sensor cover
“Bin full sensor cover removal” on
page 460
2 41X1110 1 1 Sensor (standard bin full)
with actuator
--
3 41X1083 1 1 Sensor (standard bin full)
“Sensor (standard bin full) removal”
on page 460
4 41X1083 1 1 Sensor (rear door
interlock)
“Sensor (rear door interlock)
removal” on page 452
5 41X2354 1 1 Paper size sensor cable --
640X7911 1 1Sensor (paper size)
“Sensor (paper size) removal” on
page 467
7 41X1085 1 1 Paper size sensor cover
“Sensor (paper size) removal” on
page 467
4064
Parts catalog
782
