Lexmark MS821

Assembly 8: Duplex
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X1122 1 1Duplex/MPF tray
“Duplex/MPF tray removal” on
page 434
1 41X1648 1 1 MPF tray (MS821n and
MS823n)
--
2 41X1123 1 1 MPF pick roller
“MPF pick roller removal” on
page 442
3 41X1638 1 1 MPF tray separator pad --
4 41X1635 1 1 MPF tray drive/support --
5 41X1636 1 1 MPF front door --
6 41X1124 1 1 MPF tray extension --
7 41X1631 1 1 Duplex pinch roller --
8 41X1078 1 1 Sensor (duplex path) with
cover
“Sensor (duplex path) with cover
removal” on page 466
9 41X1083 1 1 Sensor (duplex path)
“Sensor (duplex path) with cover
removal” on page 466
10 41X1050 1 1 Motor (duplex)
“Motor (duplex) removal” on
page 450
11 41X2318 1 1 Sensor/redrive motor cable --
4064
