Lexmark MS821

Assembly 12: Tray/feed
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1119 1 1 Separator pad
“Separator pad removal” on
page 464
2 41X1118 1 1 Tray insert
“Tray insert removal” on page 464
3 41X1120 1 4 Paper size sensor actuator --
4 41X2317 1 1 Feeder/paper path cable --
5 41X1108 1 1 Tray 1 pick roller
“Pick roller removal” on page 465
6 41X1107 1 1 Paper feeder
“Paper feeder removal” on page
417
7 41X2319 1 1 Feeder/paper path cable --
4064
Parts catalog
792
